ZGS□-Z•F-□/35 Wind Power Combined Transformer

The product has compact structure and good sealing performance. The high-voltage load switch, fuse, transformer body and other components of this product are all sealed in the oil tank. The oil tank is packAged by vacuum oil flling process, which completely removes the moisture in the transformer, and the transformer oil is not in contact with the atmosphere during operation, thus ensuring the insulation perormance of the transformer.

Full-range integrated high-voltage current-limiting fuse is used for protection, and the fuse structure is plug-in, which is convenient for future maintenance and replacement. The high and low voltage cabinets are respectively provided with weatherproof enclosures, which are arranged in an “L” shape, and the high voltage cabinet doors are protected by electromagnetic locks with mesh doors.

Altitude:≤2000m;

Environment temperature: -40℃-+45℃;

Environment humidity: Daily average ≤95%, monthly average ≤90%;

Installation environment: No violent vibration and impact, and no fre, explosion risk place;

Seismic capacity :8 degrees, ground horizontal acceleration ≤0.4g, ground verical acceleration ≤0.2g.

Note: If the operating environment exceeds the above range, please contact our company.
